| Resolution | 203DPI |
| Printing Method | Thermal |
| Interface | USB/Ethernet/Bluetooth/WiFi |
| Emulation | TSPL、ZPL、CPCL、DPL、EPL |
| Sensor | Gap sensor/open cover sensor/Black label sensor |
| Print Speed | 152mm/s (max) |
| Printing Width | 108mm (Max) |
| Printing Length | 1778mm (Max) |
| SDRAM | SDRAM 8MB |
| FLASH | FLASH 8MB（expandable） |
| Bar code Format | Code128、EAN128、ITF、Code39、Code93、EAN13、EAN13+2、EAN13+5、EAN8、EAN8+2、EAN8+5、CodeBar、Postnet、UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5、MSI、MSIC、PLESSEY、CPOST、ITF14、EAN14、Code11 |
| Two-dimensional code format | QR code、PDF417、Micro PDF 417、DataMatrix、AZTEC |
| Character Enlargement/rotation | 1-10x magnification /0°, 90°, 180°, 270° rotation/mirror printing |
| Character | GB18030、BIG5、ASCII |
| Extended Character | PC437、Katakana、PC850、PC860、PC863、PC865、West Europe、Greek、Hebrew、East Europe、Iran、WPC1252、PC866、PC852、PC858、IranII、Latvian、Arabic、PT151、PC747、WPC1257 and other languages, 61 kinds in total |
| Character Size | 9x17dot, 12x24dot, 24x24dot |
| Paper Type | Gap Label, Continuous Label, Black Mark Label, Folded Label, Thermal Wristband Label |
| Roll Width (including backing Paper) | 28~114mm |
| Roll Thickness (including backing Paper) | 0.12~0.26mm |
| Paper reel core | 25.4mm |
Roll outside diameter | 120mm（OD） |
| Ribbon Width | 30~110mm |
| Ribbon Length | 300m |
| Ribbon axis size | φ 25~40mm |
Ribbon Outer Diameter | 67mm（OD） |
Ribbon Winding Form | Roll-out |
| FEED | Front exit |
| Tearing Mode | Paper knife (standard) External cutter (full cut/half cut), stripper (optional) |
| Power | Input power supply: AC100 〜240V; Output power: DC 24V~2.5A |
Working Environment | Operating Temperature: 5~40°C Operating Humidity: 25~85% |
Storage Environment | Storage Temperature: -10~60℃ Storage Humidity: 10~90% |
| Print Head Life | 150km(Print rate 12.5%) |
| Dimension | 210 * 170 * 160 mm |
| Weight | 1.1KG |
Accessories (standard) | 1. Power adapter 2. Power cord 3. USB cable 4. Quick installation Guide 5, paper reel, paper roll baffle *2 6,Printing consumables *1 |
Accessories (optional) | External roll holder |
| Certification | CE, ROHS, REACH, SRRC |
